Scott 2026 Scale Gravel 20 - Kaki Green / Carbon Black - Medium

• The Scale Gravel was put on this planet for going on adventures with attitude.
• Designed to go the distance over any and all types of terrain, the Scale Gravel is lightweight with agile handling and features multiple mounting options.
• Please note that bike specifications are subject to change without prior notice.

• Frame

Scale Alloy 6061 Custom Butted Tubing, Syncros Cable Integration System
BB92, UDH Interface, 12x148mm with 55mm Chainline

• Fork

Scale Rigid HMF
Postmount Disc Standard
Tapered Carbon steerer

• Rear Derailleur

SRAM Eagle 70 Transmission 12 Speed

• Shifters

SRAM Eagle 70 Trigger

• Crankset

SRAM Eagle 70 Transmission
DUB, 55mm CL, 34T

• Chainguide

SCOTT custom

• BB-Set

SRAM DUB PF 92 MTB Wide, shell 41x92mm

• Chain

SRAM CN Eagle 70 Transmission

• Cassette

SRAM Eagle XS 1270 V2 Transmission 10-52

• Brakes

Shimano MT401 Disc Brake

• Rotor

Shimano SM-RT10 CL, 180/F and 160/R

• Handlebar

Syncros Alloy 6061
T shape Flat, 9°, 740mm
Syncros Performance XC lock-on grips

• HEAD stem

Syncros DC 3.0
Syncros Cable Integration System
0° rise, 6061 Alloy, 31.8mm, 1 1/8"

• Seatpost

Syncros, 31.6x400mm

• Seat

Syncros Belcarra V2.5 Cut Out

• Headset

Syncros - Acros OE Cable Routing HS System
OD 50/62mm, ID 42/56mm

• Front Hub

Formula CL-811, 15x110mm

• Rear Hub

Formula CL-3248, 12x148mm

• Spokes

Stainless Black 15G, 1.8mm

• Rims

Syncros X-28, 28H, Tubeless ready

• Front Tire

Maxxis Aspen, 29x2.4", 120TPI Foldable Bead
Tubeless Ready, EXO

• Rear Tire

Maxxis Aspen, 29x2.4", 120TPI Foldable Bead
Tubeless Ready, EXO

• Accessories

Spirgrips+ Inner Bar ends

• Approx weight in KG

11.4 (Tubless setup without pedals)

• Approx weight in LBS

25.13 (Tubless setup without pedals)

• Max. System Weight

120kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
